Smoke Clearance Device of Wet Scrubber
Certification: ISO
Installation Method: Vertical
Operation Type: Automatic
Medium Material: Metal Fiber
Dust Collecting Method: Dry
Type: Cyclone Dust Collector
Transport Package: Naked
Origin: China
HS Code: 84029000
Basic Info:
US$6,000.00-100,000.00 / Piece FOB Price:
1 Piece Min. Order:
Qingdao, China Port:
10sets/Month Production Capacity:
L/C, T/T, D/P, Western Union, Paypal, Money Gram Payment Terms:
84029000 HS Code:
Category & Tag:
Category: Dust Collector
Smoke Clearance Device of Wet Scrubber
DMC PULSE BAG DUST COLLECTOR WORKING PRINCIPLE
Dust smoke go into this collector from its middle part,some heavy dust due to its weight will fall down to bottom dust hopper, other light dust will go into filter of bag and stick at outside of bags, clean smoke will go through the bags and come out from top of this collector.Due to dust sticked on bags continously adding, the resistance will geting higher,when it reaches1.0-1.2kpa.pulase controller will automatically start ,pulase valve will open, and spray to all bags ,and make bags coming big suddenly,removing the dust sticked on bags, and these dust will fall down to bottom dust hopper and then drain out of the collector through discharge valve.
| Name | DMC32 | DMC48 | DMC64 | DMC80 | DMC96 | DMC112 | DMC128 |
| Filting area(m2) | 24 | 36 | 48 | 60 | 72 | 84 | 96 |
| Q of bags | 32 | 48 | 64 | 80 | 96 | 112 | 128 |
| Bag size(mm) | ø120X2000 | ||||||
| Pressure lose Pa | 1200 | ||||||
| Dust remve efficiency ‰ | 990-999 | ||||||
| Inlet smoke dust content g/m3 | ≤200 | ||||||
| Filting smoke speed m/min | 1-2 | ||||||
| Capacity m3/h | 1500-2400 | 2500-3500 | 3500-4500 | 4500-5500 | 5000-6500 | 6500-8500 | 8500-9200 |
| Pulase valve size | 1″ | 1″ | 1″ | 1″ | 1″ | 1″ | 1″ |
| Pulase valve quantity | 4 | 6 | 8 | 10 | 12 | 14 | 16 |
| Over size(mm) | 1440X760X4000 | 1440X1100X4000 | 1440X1440X4000 | 1440X1780X4200 | 1440X2120X4200 | 1440X2460X4200 | 1440X2800X4500 |
| Weight(kg) | 1350 | 1620 | 1850 | 2360 | 2800 | 3200 | 3600 |
| Supply air pressure Mpa | 0.4-0.6 | ||||||
| Fan power kw | 1.5 | 2.2 | 3 | 5.5 | 7.5 | 7.5 | 7.5 |
| Compressed air consumption m3/min | 0.13 | 0.17 | 0.21 | 0.25 | 0.3 | 0.34 | 0.42 |
| Suitale for Boiler | 1T | 1T | 1T | 1T | 2T | 2T | 3T |
