Description
BOILER /OIL HEATER INDUCED FAN DATA
| ID MODEL | GY1-15 R45° | GY2-15 R45° | GY4-15 R0° | GY6-15 R0° | GY8-15 R0° | GY10-15 R0° | GY15-15 R0° | GY20-15 R0° | Y5-47NO.14D R0° |
| ID PRESSURE | 2942-2373Pa | 3668-3020Pa | 3800-3510Pa | 4106-4057Pa | 4024-3864Pa | 3714-3802Pa | 2450-1960Pa | 3695-2811Pa | 2540Pa |
| ID FLOWRATE | 3800-6800m3/h | 5200-8500m3/h | 11500-16000m3/h | 15756-19320m3/h | 19542-22835m3/h | 26321-32138m3/h | 37754-46453m3/h | 62888-92540m3/h | 98420m3/h |
| ID MOTOR | 7.5kw | 11kw | 22kw | 37kw | 45kw | 55kw | 75kw | 110kw | 200kw |
| SUITABLE FOR BOILER | 1T/H | 2T/H | 4T/H | 6T/H | 8T/H | 10T/H | 15T/H | 20T/H | 35T/H |
| SUITABLE FOR OIL HEATER | 0.6MKCAL/H | 1.2MKCAL/H | 2.4MKCAL/H | 4MKCAL/H | 5MKCAL/H | 6MKCAL/H | 9MKCAL/H | 12MKCAL/H | 21MKCAL/H |
BOILER /OIL HEATER FORCED FAN DATA
| FD MODEL | GG1-15 R0° | GG2-15 R225° | GG4-15 R225° | GG6-15 R225° | GG8-15 R90° | GG10-15 R180° | GG15-15 R225° | GG20-15 R225° | G4-73NO.11D R90° |
| FD PRESSURE | 1834-1579Pa | 2550-3138Pa | 3314-2844Pa | 3099-2824Pa | 3099-2824Pa | 2999-2734Pa | 3704-3812Pa | 3138-2304Pa | 2540Pa |
| FD FLOWRATE | 2400-3500m3/h | 2600-4200m3/h | 3600-6000m3/h | 5800-9000m3/h | 10000-15000m3/h | 14645-20795m3/h | 23812-25435m3/h | 35000-62000m3/h | 605703m3/h |
| FD MOTOR | 4kw | 5.5kw | 11kw | 11kw | 15kw | 22kw | 37kw | 55kw | 90kw |
| SUITABLE FOR BOILER | 1T/H | 2T/H | 4T/H | 6T/H | 8T/H | 10T/H | 15T/H | 20T/H | 35T/H |
| SUITABLE FOR OIL HEATER | 0.6MKCAL/H | 1.2MKCAL/H | 2.4MKCAL/H | 4MKCAL/H | 5MKCAL/H | 6MKCAL/H | 9MKCAL/H | 12MKCAL/H | 21MKCAL/H |
